QM-HT205P 60M HDMI Extender Support IR & Loopout & POE

Introduction

The HDMI extender provides extension of HDMI signals long distances over a single CAT6/7e cable, it supports high resolution up to 1080p,support EDID copy and loopout function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.

Features

1. Transmits HDMI video and audio signals up to 60m over a single CAT6/7E cable;
2. Support video resolution up to 1920*1080@60Hz;
3. Support EDID copy function, can match many kinds of display device;
4. Support bidirectional 38KHz IR.
5. Support POE Power function, a power adapter（12V/0.5A） only connect TX .
6. Transmitter support one channel local output;
7. Follow the standard of IEEE-568B.
8. Compliance with HDMI 1.3 and HDCP 1.2 standard;
9. High compatibility, can auto-match source and display device;
10. Built-in automatic adjustment system, make the image smooth, clear and stable;
11. Built-in ESD protection system;
12. Simple to install, plug and play;

Specification

Parameter		Description
Video	Standards	HDMI 1.3; HDCP 1.2
	Maximum pixel clock	165MHz
	Maximum data rate	6.75Gbps
	Resolution	1920X1080@60Hz
	Connector	HDMI-A
	Impedance	100Ω
IR	Interface	3.5mm earphone seat
	Signal direction	bidirectional direction
	Signal type	Digital
	IR frequency	38kHz
UTP	Interface	RJ45
	RJ45 Connection	standard of IEEE-568B.
	Transmission distance	CAT6/7E: 60m；CAT5e-40m
Other	Power supply	The power adapter: DC 5-15V/1A
	Power dissipation	MAX 3W
	Temperature	Operating: -5℃ ~ +70℃
	Humidity	Operating: 5% ~ 90%
	Dimension	94.5*73*26mm
	The warranty	1 year free warranty

Panel

Connection
